PC71BM

Description

PC71BM – SOL5071

CAS: 609771-63-3

Used as an electron acceptor from Donor materials such as P3HT (SOL4106), PCDTBT (SOL4280), or PTB7 (SOL4700) to make high Open Circuit Voltage (Voc), high Power Conversion Efficiency (PCE) bulk heterojunction solar cells, >99.9% [6,6] isomerized. Available for large-scale projects.



Choose between:

Grade > 99.00% (SOL5071B)

Grade > 99.50% (SOL5071A)



Safety Data Sheet – SDS-SOL5071

Technical Data Sheet:

Acronyms:	PC71BM
Chemical Name:	[6,6]-Phenyl C71 butyric acid methyl ester
CAS#	609771-63-3
Color and Texture:	black to light brown crystalline powder
Molecular Weight:	1031 g/mol
Absorption, λmax (Media):	N/A



Emission, λmax (Media):	N/A
HOMO (eV):	-5.9 eV
LUMO (eV):	-3.9 eV
Melting point (°C):	N/A
Solubility (Solvent):	toluene, chloroform, chlorobenzene
Other:	N/A



Request pricing for larger quantity

* Price subject to change without prior notice

Products for Research and Development. Laboratory use only by qualified personnel. The user should read the available SDS and be aware of any precaution to take for the safe manipulation of these materials. Solarischem shall not be held responsible for any damage resulting from the use or handling of these products. Any product can be discontinued, specifications altered or price changed at any time without prior notice. The specifications and structures do not guarantee any product’s suitability for the client’s applications or uses.
